WorkPro Integra 32 Digital Audio Matrix 32 X 32 Channels dsp - Black
only 1 item(s) remaining
SAR 0.00
Rate inclusive of VAT
Sold By : ksam4music
Fulfilled by Thomsun Industries
-
+
- Condition: New
WorkPro Integra 32+ (58WIN018): 32x32 DSP matrix with 16 analog/Euroblock + 16 Dante I/O, 31-band EQ, AEC/feedback suppression, automix, 1U rackmount.
Model :58WIN018
SKU :
This item cannot be returned or exchanged
Cash on Delivery available Description for WorkPro Integra 32 Digital Audio Matrix 32 X 32 Channels dsp - Black
Introducing the INTEGRA 32 + digital matrix, where control and creativity have never been easier. Our free and powerful native management software puts the power in your hands.
With configurable per-channel DSP architecture, adjust gain, EQ, compression, limiting and more, all with one-click ease. The visual matrix and auto-mix module give you unparalleled flexibility.
Filter bank on the inputs, independent compression/limiting on each output, DANTE digital inputs, and an APP for mobile devices to control everything from your pocket
Main information
- 16 X 16 analog channels + 16 X 16 DANTE channels
- Programmable DSP architecture per channel
- Customizable control software and APP
- Audio processor IC 24 bit / 48kHz Shark 450 MHz
| Category | Specification | Details |
|---|---|---|
| Audio | Input Channels | 16 Analog Balanced (Euroblock) + 16 Dante |
| Output Channels | 16 Analog Balanced (Euroblock) + 16 Dante | |
| Input Processing | Expander, Compressor, Auto Gain Compensation, EQ (up to 31 bands), Feedback Suppressor | |
| Output Processing | Filters (Bessel, Butterworth, Linkwitz-Riley), EQ (up to 31 bands), Delay, Limiter | |
| THD+N | 0.003% @ 4dBu | |
| Maximum Output Level | +18dBu | |
| Sampling Frequency | 24-bit / 48 kHz | |
| Control | Protocols | RS232, RS485, UDP, TCP, 8 GPIOs |
| Network Ports | RJ45 Ethernet, Dante Primary/Secondary | |
| Physical | Dimensions (W x D x H) | 482 x 260 x 45 mm |
| Weight | 3 kg | |
| Power Supply | AC 110~240V 50/60Hz | |
| Consumption | <40W | |
| Functions | Key Features | Signal matrix, Automix, 3 filters/input, Polarity inversion, Noise gate, Compressor, Delay, 5 EQ types, Signal generators (Sine/Pink/White noise), Acoustic Echo Cancellation, Automatic Noise Suppressor |
| Software | Integra+ DSP (PC), Integra REMOTE (Tablet/Smartphone) | |
| Memories | 16 Presets |
