RØDE Caster Video S Production Console - Black

Description for RØDE Caster Video S Production Console - Black

The RØDECaster Video S is a revolutionary all-in-one video and audio production console designed to deliver intuitive control over every element of your content. A compact version of the RØDECaster Video, it combines powerful video switching, recording and production capabilities with a fully integrated professional audio mixer. From video podcasts and studio productions to live streams and interviews, the RØDECaster Video S provides a seamless way to streamline and supercharge your workflow with broadcast-quality results.

Key Features

• Switch between up to four video sources and five fully customisable scenes at the press of a button
• High-performance octa-core CPU video and audio processor
• Three full HD (1080p) HDMI inputs with auto frame rate conversion and one configurable HDMI output for viewing program, preview and multi-view
• One flexible USB-C port for connecting webcams and RØDE USB audio devices to use as additional video and audio sources
• Two studio-grade Neutrik® combo jacks with ultra-low-noise, high-gain Revolution Preamps™ for capturing pristine audio from XLR microphones, instruments or any other audio source
• Dual internal wireless receivers for connecting RØDE Series IV wireless microphones
• Powerful APHEX® audio processing, including an EQ, compressor, noise gate, high-pass filter, de-esser and the legendary Aural Exciter™, Big Bottom™ and Compellor™ effects
• Support for network cameras (including PTZ operation) with up to four NDI inputs® and one output via Ethernet, plus dual-cam streaming with the free RØDE Capture app for iOS devices
• 2-inch high-resolution touchscreen and versatile rotary encoder for quick configuration and setting adjustment
• Ability to create five complex scenes with multiple layers of video, media and graphics, which can be saved and triggered at the touch of a button
• Automatic chroma keying for effortlessly replacing backgrounds with media or live video inputs
• Media playback, graphic overlays, keying, transitions and multi-source scene creation all accessible from the front panel
• Innovative "Inspect" feature for quick-and-easy preview and configuration of any input or scene
• Intelligent auto-switching for seamless hands-free switching of video sources and scenes based on audio inputs
• Stream directly to all major platforms via Wi-Fi or Ethernet, or to streaming software via USB
• Record directly to external USB storage device, including isolated (ISO) recording for post-editing flexibility
• Remote control, user-assignable graphics and media, custom scene building, audio mixing and effects, and other advanced configuration options via the RØDECaster App
• Designed and made in RØDE’s state-of-the-art facilities in Sydney, Australia
• 24GB of on-board storage (20GB user-configurable) for media, graphics and overlays



  Category	Specification	Details
  Video Engine	Total Layers	9 simultaneous (Preview + Program)
  	Downstream Keyers	2
  	Chroma Keyers	2 (Green/Blue)
  	Media Players	2 simultaneous
  	Transitions	SMPTE wipes, dip, fade
  	Multiview	Program, preview, inputs, audio/status
  Video Inputs	Total Feeds	4 simultaneous
  	HDMI Inputs	3x Type-A (HDMI 1.4b)
  	USB UVC Input	1x USB-C
  	Frame Rates (1080p)	23.98-60 fps
  Video Outputs	HDMI Output	1x (Preview/Program/Multiview)
  Streaming	Direct RTMP	YouTube/Twitch/Facebook/Twitter/Custom
  	Network	Ethernet/Wi-Fi 6
  Media Storage	Capacity	24GB onboard (MP4/PNG/WAV)
  Audio Inputs	Analog	2x combo (Revolution Preamps)
  	Wireless	2x Series IV
  	Digital	3x USB + Bluetooth 5.3
  Audio Processing	Features	APHEX VoxLab (EQ/Comp/De-esser/Gate)
  Recording	Video	Program + ISO (4 inputs + PGM)
  	Audio	Stereo mix + 9-track multitrack
  Physical	Weight	875 g
  	Dimensions (L x W x H)	253.5 x 128.4 x 60.2 mm
