REAN RP3C 1/4" Stereo TRS Plug - Black
.png)
REAN RP3C Black: Ergonomic finger-groove 1/4" stereo jack with POM strain relief, reinforced PA boot, nickel/black shell plating options, and gold contact variants for premium instrument cables.
Model :REANRP3CBD
SKU :
This item cannot be returned or exchanged
Cash on Delivery available Description for REAN RP3C 1/4" Stereo TRS Plug - Black
REAN REANRP3CBD RP3C is a compact 3-pole 1/4" TRS stereo plug with black zinc alloy housing, designed for professional audio cable assembly supporting balanced mono or stereo connections up to 7mm cable diameter.
Specs المواصفات
| Category | Specification | Details |
|---|---|---|
| Electrical | Contact Resistance | Depends on mating connector |
| Dielectric Strength | 1 kV DC | |
| Insulation Resistance | >1.5 GΩ | |
| Mechanical | Lifetime | >1000 mating cycles |
| Cable OD | 4-7 mm | |
| Wire Size (max) | 1.0 mm² / 18 AWG | |
| Wiring | Solder contacts | |
| Materials | Contacts | Brass (CuZn39Pb3), nickel/Au plating |
| Shell | Zinc alloy, nickel/black plating | |
| Boot | PA6+30% GF | |
| Strain Relief | POM | |
| Environmental | Temperature Range | -20°C to +70°C |
| Flammability | UL 94 HB |
